FAQ
Where can I get service and/or consumable parts for Kemppi equipment?

You can get service and consumables from your nearest Kemppi representative. Please see our representatives near you.

How can I find the closest Kemppi service workshop near me?

You can find the closest repair workshop from our map search.

What kind of a warranty does Kemppi equipment have?

Kemppi welding equipment is designed and tested for professional industrial environments. As a guarantee of high quality, we offer our customers a global warranty up to three years.

For full details, see Kemppi Warranty.

Mains and generator use, what do I need to do if anything?

If no mains connection is available, you can use FastMig X 350 and X 450 on a generator. The minimum recommended generator output is 35 kVA. The greater the output, the more stable is the FastMig X power source operation.

On my FastMig X machine, what is the normal cooling fan sequence, start up and in operation?

FastMig X power sources incorporate two simultaneously operating fans.

  • The fan is started momentarily when the main switch is turned into position I.
  • The fan will start during welding as the machine reaches operational temperature, and it will continue running for 1 to 10 minutes after the welding has stopped, depending on the welding cycle completed.
How to change gas cooled / water cooled selection?

The factory default setting for FastMig X is AUTO. If a cooling unit is not connected and the operator tries to establish air-cooled operation together with an air-cooled gun, Err 27 is displayed. To establish air-cooled operation, select cooler ‘OFF’.

This is done in the ‘System Config Menu’ as follows: Press the Menu button on the X 37 power source panel. Move the menu display arrow (via panel's left-hand up-down arrow keys) to select ‘System Config Menu’ and then press the select button. Choose ‘Water Cooling:Auto’ and change via control knob to setting ‘Water Cooling:OFF’, then press Back/Exit. Cooler will then be set to the ‘OFF’ state for air-cooled operation. Reset power source via on/off switch and continue welding.

When selected, the operation of the cooling unit is automatic, starting when welding commences. When welding stops the pump will continue operation for approx. 5 min, so reducing the gun and the cooling liquid to ambient temperature.

Intelligent, flexible, upgradable

Kemppi's FastMig X product series offers highly specialized welding solutions and superior welding quality for demanding industrial applications. It features three alternative high-end configuration recommentations for three different purposes: FastMig X Regular for robust workshop use a MIG/MAG pulse welding, mainly for welding thick plates, FastMig X Pipe for pipe and root welding and FastMig X Intelligent for demanding welding applications, for all metals and processes, including welding of thin sheets.

All configurations are equipped with either the FastMig X 350 or the FastMig X 450 power source, which is a multi-process CC/CV power source that is ideal for synergic and pulsed MIG/MAG welding, MMA welding, and TIG welding. Used in configuration with WFX wire feeders, they form a welding system that easily meets every welding need and the quality management requirements of any metal fabrication workshop. Additionally, all three configurations come with the Cool X cooling unit.

Benefits

  • Multi-process power solution: MIG, 1-MIG, pulsed MIG, MMA, and TIG
  • Arc Mobile Control brings flexible way to use and control the welding machine
  • WiseRoot+ for optimized root welding
  • WiseThin + for optimized sheet and position welding: Mixed gas quality with lower cost CO2 shielding gas
  • Precise arc voltage function measures and shows the actual arc voltage on the display
  • Save time by combining two wire feeders on the same power sourcefor alternative filler wires
  • SuperSnake subfeeder connectivity for maximum reach
Download brochure Watch video
FASTER WELDING

FASTER WELDING

Boost your efficiency by utilizing up to 30 % faster travel speeds with WiseFusion

LOWER HEAT INPUT

LOWER HEAT INPUT

Reduce distortion and time consuming straightening work and improve the impact toughness of high strength steels with WiseFusion

BEST REACH ON THE MARKET

BEST REACH ON THE MARKET

Distance and access will no longer be a problem with the SuperSnake subfeeder accessory

Product options

All Regular Pipe

Power sources

FastMig X 450 Power source
FastMig X 450 Power source Provides 450 A with 60% duty cycle. Suitable for generator use. View more
Technical specifications
Product code
6103450
Connection voltage 3~ 50/60 Hz
400 V, (-15…+20%)
Fuse (delayed)
35A
Minimum generator power
35 kVA
Output 60% ED
450 A
Output 100% ED
350 A
Open circuit voltage MMA
U0 = 70-98 V Uav = 50 V
Open circuit voltage MIG/MAG
U0 = 80 - 98 V
Operating temperature range
-20 ... +40 °C
External dimensions LxWxH
590 × 230 × 430 mm
Degree of protection
IP23S
Standards
IEC 60974-1, IEC 60974-5, IEC 60974-10

Wire feeders

WFX 200 Wire feeder
WFX 200 Wire feeder For Ø 200 mm wire spools. Strong double-skin plastic casing with a reliable DuraTorque wire feed mechanism. Built-in arc voltage measurement. View more
Technical specifications
Product code
6103520
Output 60% ED
520 A
Output 100% ED
440 A
Wire feed mechanism
4 roll
Wire feed speed
1 - 25 m/min
Gun connection
Euro
Wire spool weight, max.
5 kg
Wire spool diameter, max.
200 mm
Filler wire sizes (Ss)
0.6 - 1.6 mm
Filler wire sizes (Al)
0.8 - 2.4 mm
Filler wire sizes (Fe)
0.6 - 1.6 mm
Filler wire sizes (Cored wire)
0.8 - 2.0 mm
Software
WiseFusion WorkPack (21pcs)
Operating temperature range
-20 ... +40 °C
External dimensions LxWxH
510 × 200 × 310 mm
Degree of protection
IP23S
Standards
IEC 60974-5
Weight (empty)
9.4 kg
WFX 300 Wire feeder
WFX 300 Wire feeder For Ø 200/300 mm wire spools. Strong double-skin plastic casing with a reliable DuraTorque wire feed mechanism. Built-in arc voltage measurement. View more
Technical specifications
Product code
6103530
Output 60% ED
520 A
Output 100% ED
440 A
Wire feed mechanism
DuraTorque
Wire feed speed
1 - 25 m/min
Gun connection
Euro
Wire spool weight, max.
20 kg
Wire spool diameter, max.
300 mm
Filler wire sizes (Ss)
0.6 - 1.6 mm
Filler wire sizes (Al)
0.8 - 2.4 mm
Filler wire sizes (Fe)
0.6 - 1.6 mm
Filler wire sizes (Cored wire)
0.8 - 2.0 mm
Software
WiseFusion WorkPack (21pcs)
Operating temperature range
-20 ... +40 °C
External dimensions LxWxH
625 × 243 × 476 mm
Degree of protection
IP23S
Standards
IEC 60974-5
Weight (empty)
12.5 kg
WFX 200 P Fe Wire feeder
WFX 200 P Fe Wire feeder For steel pipe welding with Ø 200 mm wire spools. Strong double-skin plastic casing with a reliable DuraTorque wire feed mechanism. Built-in arc voltage measurement. View more
Technical specifications
Product code
6103521
Output 60% ED
520 A
Output 100% ED
440 A
Wire feed mechanism
4 roll
Wire feed speed
1 - 25 m/min
Gun connection
Euro
Wire spool weight, max.
5 kg
Wire spool diameter, max.
200 mm
Filler wire sizes (Ss)
0.6 - 1.6 mm
Filler wire sizes (Al)
0.8 - 2.4 mm
Filler wire sizes (Fe)
0.6 - 1.6 mm
Filler wire sizes (Cored wire)
0.8 - 2.0 mm
Software
WiseFusion WiseRoot+ MatchLog Pipe Steel pack Fe (25pcs)
Operating temperature range
-20 ... +40 °C
External dimensions LxWxH
510 × 200 × 310 mm
Degree of protection
IP23S
Standards
IEC 60974-5
Weight (empty)
9.4 kg
WFX 200 P Ss Wire feeder
WFX 200 P Ss Wire feeder For stainless steel pipe welding with Ø 200 mm wire spools. Strong double-skin plastic casing with a reliable DuraTorque wire feed mechanism. Built-in arc voltage measurement. View more
Technical specifications
Product code
6103522
Output 60% ED
520 A
Output 100% ED
440 A
Wire feed mechanism
4-roll
Wire feed speed
1 - 25 m/min
Gun connection
Euro
Wire spool weight, max.
5 kg
Wire spool diameter, max.
200 mm
Filler wire sizes (Ss)
0.6 - 1.6 mm
Filler wire sizes (Al)
0.9 - 2.4 mm
Filler wire sizes (Fe)
0.6 - 1.6 mm
Filler wire sizes (Cored wire)
0.8 - 2.0 mm
Software
WiseFusion WiseRoot+ MatchLog Pipe Stainless pack Ss (17pcs)
Operating temperature range
-20 ... +40 °C
Degree of protection
IP23S
Weight (empty)
9.4 kg
External dimensions
510 × 200 × 310 mm
WFX 300 P Fe Wire feeder
WFX 300 P Fe Wire feeder For steel pipe welding with Ø 200/300 mm wire spools. Durable double-skin plastic casing with a strong two-motor GT04 wire feed mechanism. Built-in arc voltage measurement. View more
Technical specifications
Product code
6103531
Output 60% ED
520 A
Output 100% ED
440 A
Wire feed mechanism
GT04
Wire feed speed
0.5 - 25 m/min
Gun connection
Euro
Wire spool weight, max.
20 kg
Wire spool diameter, max.
300 mm
Filler wire sizes (Ss)
0.6 - 2.0 mm
Filler wire sizes (Al)
0.8 - 2.4 mm
Filler wire sizes (Fe)
0.6 - 2.0 mm
Filler wire sizes (Cored wire)
0.8 - 2.4 mm
Software
WiseFusion WiseRoot+ MatchLog Pipe Steel pack Fe (25pcs)
Operating temperature range
-20 ... +40 °C
External dimensions LxWxH
590 × 240 × 445 mm
Degree of protection
IP23S
Standards
IEC 60974-5
Weight (empty)
13.1 kg
WFX 300 P Ss Wire feeder
WFX 300 P Ss Wire feeder For stainless steel pipe welding with Ø 200/300 mm wire spools. Durable double-skin plastic casing with a strong two-motor GT04 wire feed mechanism. Built-in arc voltage measurement. View more
Technical specifications
Product code
6103532
Output 60% ED
520 A
Output 100% ED
440 A
Wire feed mechanism
GT04
Wire feed speed
1 - 25 m/min
Gun connection
Euro
Wire spool weight, max.
20 kg
Wire spool weight, max.
20 kg
Wire spool diameter, max.
300 mm
Wire spool diameter, max.
300 mm
Filler wire sizes (Ss)
0.6 - 2.0 mm
Filler wire sizes (Al)
0.8 - 2.4 mm
Filler wire sizes (Fe)
0.6 - 2.0 mm
Filler wire sizes (Cored wire)
0.8 - 2.4 mm
Software
WiseFusion WiseRoot+ MatchLog Pipe Stainless pack Ss (17pcs)
Operating temperature range
-20 ... +40 °C
Degree of protection
IP23S
Weight (empty)
13.1 kg
External dimensions
590 × 240 × 445 mm

Software

WiseFusion
WiseFusion A welding function that ensures consistent weld quality in all positions by automatically regulating arc length. Creates and maintains an optimal short-circuit characteristic in pulsed MIG/MAG and spray-arc welding. View more
Product code
X5500001 (Product code for X5 FastMig)
X8500000 (Product code for X8 MIG Welder)
MSM40000 (Product code for Master M)
AX30000 (Product code for AX MIG Welder)
WiseRoot+
WiseRoot+ Optimized short arc process for productive root pass welding. Excellent weld quality through control of arc voltage and timing of filler metal droplet transfer. Gives higher speed than MMA, TIG or MIG/MAG short arc welding. View more
Product code
X8500003 (Product code for X8 MIG Welder)
X5500003 (Product code for X5 FastMig)
AX40000 (Product code for AX MIG Welder)

Accessories

All Guns Software Cooling Remotes Cables Other
Kemppi Cool X Cooling unit product image

Cool X Cooling unit

Cool X cooling unit for liquid-cooled setups is the ultimate choice providing 1 kW of...

Cool X cooling unit for liquid-cooled setups is the ultimate choice providing 1 kW of cooling power with 3 liters of cooling liquid.

Product code: 6068200 Cooling liquid - 10 liter can - SP9810765


Flexlite GX

Flexlite GX product series contains welding guns to be used in MIG/MAG welding proces...

Flexlite GX product series contains welding guns to be used in MIG/MAG welding processes. All Flexlite GX welding guns enjoy the Flexlite features for user comfort, welding efficiency and extended consumable parts life.

Kemppi Earth return cable 5 m, 50 mm² product image

Earth return cable 5 m, 50 mm²

Product code: 6184511

Kemppi Earth return cable 5 m, 70 mm² product image

Earth return cable 5 m, 70 mm²

Product code: 6184711

Kemppi Cable for Stick (MMA) welding 5 m, 70 mm² product image

Cable for Stick (MMA) welding 5 m, 70 mm²

Product code: 6184701

Kemppi Cable for Stick (MMA) welding 5 m, 50 mm² product image

Cable for Stick (MMA) welding 5 m, 50 mm²

Product code: 6184501

Kemppi Remote control extension cable 10 m product image

Remote control extension cable 10 m

Product code: 6185481

Kemppi ARC Mobile Control product image

ARC Mobile Control

For the first time in welding history, you can now control and monitor your welding m...

For the first time in welding history, you can now control and monitor your welding machine wirelessly via a smartphone or tablet computer.

Download the app from Google Play.

Kemppi KWF 200/300 cabinet heater product image

KWF 200/300 cabinet heater

The cabinet heater maintains a temperature level inside the wire feed cabinet for con...

The cabinet heater maintains a temperature level inside the wire feed cabinet for conditions where the ambient temperature cycles up and down.

This unit is suitable for MXF 63, 65, 67, MXP 37 PIPE, and MXP 38.

Product code: 6185288

Kemppi GH 30 Gun holder product image

GH 30 Gun holder

GH 30 Gun holder increases the usability around the workshop. The gun holder can be m...

GH 30 Gun holder increases the usability around the workshop. The gun holder can be mounted on a welding machine, transport unit, or welding table.

Product code: 6256030


DataGun

Kemppi DataGun is a programming device that is used together with Kemppi DataStore on...

Kemppi DataGun is a programming device that is used together with Kemppi DataStore online shop to purchase and install welding software and upgrades to your Kemppi welding machines.

Kemppi GXR10 - gun remote product image

GXR10 - gun remote

On-torch remote control for Flexlite GX series 5 welding guns allows accurate and imm...

On-torch remote control for Flexlite GX series 5 welding guns allows accurate and immediate welding current adjustment and memory channel selection.

Product code: GXR10

Kemppi Remote control R30 product image

Remote control R30

Suitable for use with Kemppi FastMig X and FastMig M with MXF wire feeder. Available ...

Suitable for use with Kemppi FastMig X and FastMig M with MXF wire feeder. Available in 5 m and 10 m.

Increase welding quality, work efficiency, comfort, and safety with appropriate, easy-to-use Kemppi remote controls.

Product code: R30, 5 m - 6185420 R30, 10 m - 618542001

Kemppi Remote X 37 control panel product image

Remote X 37 control panel

Product code: 6103800

Kemppi FASTMIG X 70-1.8-GH interconnection air-cooled cable, 1.8 m product image

FASTMIG X 70-1.8-GH interconnection air-cooled cable, 1.8 m

Product code: 6260468

Kemppi FASTMIG X 70-5-GH interconnection air-cooled cable, 5 m product image

FASTMIG X 70-5-GH interconnection air-cooled cable, 5 m

Product code: 6260469

Kemppi FASTMIG X 70-10-GH interconnection air-cooled cable, 10 m product image

FASTMIG X 70-10-GH interconnection air-cooled cable, 10 m

Product code: 6260470

Kemppi FASTMIG X 70-20-GH interconnection air-cooled cable, 20 m product image

FASTMIG X 70-20-GH interconnection air-cooled cable, 20 m

Product code: 6260471

Kemppi FASTMIG X 70-30-GH interconnection air-cooled cable, 30 m product image

FASTMIG X 70-30-GH interconnection air-cooled cable, 30 m

Product code: 6260472

Kemppi FASTMIG X 70-1.8-WH interconnection liquid-cooled cable, 1.8 m product image

FASTMIG X 70-1.8-WH interconnection liquid-cooled cable, 1.8 m

Product code: 6260473

Kemppi FASTMIG X 70-5-WH interconnection liquid-cooled cable, 5 m product image

FASTMIG X 70-5-WH interconnection liquid-cooled cable, 5 m

Product code: 6260474

Kemppi FASTMIG X 70-10-WH interconnection liquid-cooled cable, 10 m product image

FASTMIG X 70-10-WH interconnection liquid-cooled cable, 10 m

Product code: 6260475

Kemppi FASTMIG X 70-20-WH interconnection liquid-cooled cable, 20 m product image

FASTMIG X 70-20-WH interconnection liquid-cooled cable, 20 m

Product code: 6260476

Kemppi FASTMIG X 70-30-WH interconnection liquid-cooled cable, 30 m product image

FASTMIG X 70-30-WH interconnection liquid-cooled cable, 30 m

Product code: 6260477


Magnetic clamp (earth return cable)

600 A

600 A

Product code: 9871570


Magnetic clamp (voltage sensing cable)

200 A

200 A

Product code: 9871580

Kemppi MatchLog product image

MatchLog

MatchLog includes Minilog and MatchChannel activation in WFX feeders (Minilog can be ...

MatchLog includes Minilog and MatchChannel activation in WFX feeders (Minilog can be used only with MXF feeders).
MatchChannel allows changing of the memory channel during welding and Minilog enables to change welding power in the same memory channel.

Product code: 9991017

Kemppi KFH 1000 product image

KFH 1000

KFH 1000 is a movable option for hanging cables. This solution helps to create more v...

KFH 1000 is a movable option for hanging cables. This solution helps to create more versatile work spaces around the workshop.

This unit is suitable for MXF 63, 65, 67, MXP 37 PIPE, MXP 38, WFX 200, 200 P, 200 AMC
WFX 300, 300 P, 300 AMC and ArcFeed.

Product code: 6185100

Kemppi Boom WP 6000 product image

Boom WP 6000

Articulated boom “WP 6000” holds one wire feeder and creates a semicircular working a...

Articulated boom “WP 6000” holds one wire feeder and creates a semicircular working area of 6 meters in radius. The boom folds in the middle and rotates 180 degrees, making it possible to reach the areas close to the wall, unlike with telescopic booms. The maximum load is 50 kg.

For suspension, a suitable Kemppi wire feeder hanger must be used: X8 Wire Feeder: X8702040000, WFX 300: 6185100, MFX 63: 6185285, MXF 65: W001694.

Product code: 6264026

Kemppi Digital Connectivity Module product image

Digital Connectivity Module

An accessory device that enables integration with WeldEye cloud service. Collects wel...

An accessory device that enables integration with WeldEye cloud service. Collects welding data from the power source and transfers it wirelessly to the WeldEye mobile app. The connection might require an adapter depending on the welding machine model.

Product code: 6265051

Support

Need
consumables?

Need
consumables?

Need repairs or maintenance?

Need repairs or maintenance?

Warranty

Warranty

Frequently asked questions

Frequently asked questions

Close

Technical specifications
