MinarcMig Evo Downloads
Manuals
MinarcMig Evo 170, 200 PDF Manual
MinarcMig Evo 170, 200 (AU) PDF Manual
MinarcMig Evo 170/200 [object Object]
Technical specifications
MinarcMig Evo 170 Download
MinarcMig Evo 170 AU Download
MinarcMig Evo 170 DK Download
MinarcMig Evo 200 Download
MinarcMig Evo 200 AU Download
MinarcMig Evo 200 DK Download
Declarations of conformity
MinarcMig Evo 170, 200 Download
MinarcMig Evo 170, 200 (AU) Download
Videos
MinarcMig Evo 200 Watch video
Wherever work takes you Watch video
FAQ
Where can I get service and/or consumable parts for Kemppi equipment?

You can get service and consumables from your nearest Kemppi representative. Please see our representatives near you.

How can I find the closest Kemppi service workshop near me?

You can find the closest repair workshop from our map search.

What kind of a warranty does Kemppi equipment have?

Kemppi welding equipment is designed and tested for professional industrial environments. As a guarantee of high quality, we offer our customers a global warranty up to three years.

For full details, see Kemppi Warranty.

Mains and generator use, what do I need to do if anything?

The minimum power for the generator is 4.2 kVA, and the recommended power 8.0 kVA in order for the machine to be used at maximum capacity.

On my MinarcMig Evo 170/200 machine, what is the normal cooling fan sequence, start up and in operation?

When the machine is switched off, the DC link is discharged by the fan running for a short time.

An adaptive tool for the mobile welder

MinarcMig Evo machines pack huge MIG/MAG welding capacity and quality into their portable, compact size. Choose from either 200 A or 170 A models, delivering their welding power at 35 % duty cycle from a 16 A, 1-phase mains supply. MinarcMig Evo delivers premium results wherever your work takes you.

MinarcMig Evo 200 offers Automatic and Manual mode set-up for precise welding quality and arc ignition, monitored and controlled by Kemppi’s adaptive arc regulation system. MinarcMig Evo 170 offers manual setting only, with separate controls for voltage and wire feed speed.

Benefits

  • Precise weld quality and arc ignition
  • 200 A / 170 A of MIG/MAG welding power from a 16 A supply
  • Choose either Automatic or Manual model
  • Use with Fe, Fe FCW, Ss, Al, CuSi filler wires, 1 kg and 5 kg spools
  • Just set the plate thickness and weld with 200 A model
  • Large graphical display guides user
  • Designed for use with long supply cables of 100m+
  • A 3-meter gun, cable set and carrying strap included
  • Suitable for mains network or generator use
  • Kemppi 3+ warranty for parts and labour
Buy Download brochure
LIGHTWEIGHT AND PORTABLE

LIGHTWEIGHT AND PORTABLE

No extra lift assist required

Less electromagnetic interference

Less electromagnetic interference

On electrical network due to PFC technology

Cable length possible

Cable length possible

For increased utility in site welding environments

Select your product

Welding power requirement
  • All
  • 170 A
  • 200 A
Control interface
  • All
  • Adaptive power regulation
  • Standard control inc meters
MinarcMig Evo 200
MinarcMig Evo 200 200 A, 1-phase, Adaptive power regulation View more
Technical specifications
Download
Buy
Product code
61008200
Connection voltage 1~ 50/60 Hz
230 V ±15%
Fuse (delayed)
16A
Minimum generator power
4.2 kVA
Welding range
20 A/15 V – 200 A/26 V
Output 35% ED
200 A/24 V
Output 60% ED
160 A/22 V
Output 100% ED
120 A/20 V
Open circuit voltage
70-75 V
Wire spool weight, max.
5 kg
Wire spool diameter, max.
200 mm
Operating temperature range
-20…+40 °C
External dimensions LxWxH
450 × 227 × 368 mm
Weight (no accessories)
13 kg
Degree of protection
IP23S
Standards
IEC 60974-1, IEC 60974-5, IEC 60974-10, IEC 61000-3-12
MinarcMig Evo 200 DK
MinarcMig Evo 200 DK 200 A, 1-phase, Adaptive power regulation View more
Technical specifications
Download
Product code
61008200DK
Connection voltage 1~ 50/60 Hz
230 V ±15%
Fuse (delayed)
16A
Minimum generator power
4.2 kVA
Welding range
20 A/15 V – 200 A/26 V
Output 35% ED
200 A/24 V
Output 100% ED
120 A/20 V
Open circuit voltage
70-75 V
Wire spool weight, max.
5 kg
Wire spool diameter, max.
200 mm
Operating temperature range
-20…+40 °C
External dimensions LxWxH
450 × 227 × 368 mm
Weight (no accessories)
13 kg
Degree of protection
IP23S
Standards
IEC 60974-1, IEC 60974-5, IEC 60974-10, IEC 61000-3-12
MinarcMig Evo 170
MinarcMig Evo 170 170 A, 1-phase, Standard control inc meters View more
Technical specifications
Download
Buy
Product code
61008170
Connection voltage 1~ 50/60 Hz
230 V ±15%
Fuse (delayed)
16A
Minimum generator power
4.2 kVA
Welding range
20 A/15 V – 170 A/24 V
Output 35% ED
170 A/24 V
Output 100% ED
100 A/20 V
Open circuit voltage
70-75 V
Wire spool weight, max.
5 kg
Wire spool diameter, max.
200 mm
Operating temperature range
-20…+40 °C
External dimensions LxWxH
450 × 227 × 368 mm
Weight (no accessories)
13 kg
Degree of protection
IP23S
Standards
IEC 60974-1, IEC 60974-5, IEC 60974-10, IEC 61000-3-12
MinarcMig Evo 170 AU
MinarcMig Evo 170 AU 170 A, 1-phase, Standard control inc meters View more
Technical specifications
Download
Product code
61008170AU
Connection voltage 1~ 50/60 Hz
240 V ±15%
Fuse (delayed)
16A
Minimum generator power
4.2 kVA
Welding range
20 A/15 V – 170 A/24 V
Output 35% ED
170 A/24 V
Output 100% ED
100 A/20 V
Open circuit voltage
70-75 V
Wire spool weight, max.
5 kg
Wire spool diameter, max.
200 mm
Operating temperature range
-20…+40 °C
External dimensions LxWxH
450 × 227 × 368 mm
Weight (no accessories)
13 kg
Degree of protection
IP23S
Standards
IEC 60974-1, IEC 60974-5, IEC 60974-10, IEC 61000-3-12
MinarcMig Evo 170 DK
MinarcMig Evo 170 DK 170 A, 1-phase, Standard control inc meters View more
Technical specifications
Download
Product code
61008170DK
Connection voltage 1~ 50/60 Hz
230 V ±15%
Fuse (delayed)
16A
Minimum generator power
4.2 kVA
Welding range
20 A/15 V – 170 A/24 V
Output 35% ED
170 A/24 V
Output 100% ED
100 A/20 V
Open circuit voltage
70-75 V
Wire spool weight, max.
5 kg
Wire spool diameter, max.
200 mm
Operating temperature range
-20…+40 °C
External dimensions LxWxH
450 × 227 × 368 mm
Weight (no accessories)
13 kg
Degree of protection
IP23S
Standards
IEC 60974-1, IEC 60974-5, IEC 60974-10, IEC 61000-3-12
MinarcMig Evo 200 AU
MinarcMig Evo 200 AU 200 A, 1-phase, Adaptive power regulation View more
Technical specifications
Download
Product code
61008200AU
Connection voltage 1~ 50/60 Hz
240 V ± 15%
Fuse (delayed)
16A
Minimum generator power
4.2 kVA
Welding range
20 A/15 V – 200 A/26 V
Output 35% ED
200 A/24 V
Output 100% ED
120 A/20 V
Open circuit voltage
70-75 V
Wire spool weight, max.
5 kg
Wire spool diameter, max.
200 mm
Operating temperature range
-20…+40 °C
External dimensions LxWxH
450 × 227 × 368 mm
Weight (no accessories)
13 kg
Degree of protection
IP23S
Standards
IEC 60974-1, IEC 60974-5, IEC 60974-10, IEC 61000-3-12

Features

Simply set the plate thickness and weld

MinarcMig Evo 200 automatically sets the machine based on your input selections for plate thickness in mm, weld shape and material type. Easy single knob control allows you to make the selections while the large graphical interface guides you through the process, leaving no room for guessing.

Watch video

Wherever work takes you

Compact and portable welding power from the Minarc Evo product family for MIG/MAG, TIG and stick (MMA) welding.

Watch video

MinarcMig Evo 200

The ideal solution for welding professionals on the move, packing huge welding capacity and quality into its compact size.

Energy economy and welding utility

PFC power source technology offers the ultimate energy economy with a power factor of 0.99. MinarcMig Evo can also be used efficiently with extra long power supply cables of more than 100 meters long, allowing for optimum welding utility in site welding environments.

Accessories

All Cables Transport unit Series 3 welding guns Other
Kemppi GC 223G product image

GC 223G

220 A, Gas-cooled, 3m, MinarcMig Connector

220 A, Gas-cooled, 3m, MinarcMig Connector

Product code: GC223GMM3 (3m)

Download
Buy
View more View less
Kemppi Earth return cable 3 m, 25 mm² product image

Earth return cable 3 m, 25 mm²

Product code: 6184004

View more View less
Kemppi Shielding gas hose 4.5 m product image

Shielding gas hose 4.5 m

Product code: W001077

View more View less
Kemppi Shoulder strap product image

Shoulder strap

Product code: 9592163

View more View less
Kemppi MST 400 product image

MST 400

Suitable for MinarcMig, MinarcMig Evo, MinarcTig, MinarcTig Evo, and Minarc 220....

Suitable for MinarcMig, MinarcMig Evo, MinarcTig, MinarcTig Evo, and Minarc 220.

The MST 400 is a 2-wheel transport unit that is recommended for smaller gas bottle sizes.

Product code: 6185294

View more View less
Kemppi Euro Adapter for MinarcMig and MinarcMig Evo product image

Euro Adapter for MinarcMig and MinarcMig Evo

Euro Adapter for MinarcMig and MinarcMig Evo takes your connectivity to a whole new l...

Euro Adapter for MinarcMig and MinarcMig Evo takes your connectivity to a whole new level.

Product code: Euro adapter kit - W008366 Wire liner, 0.6-0.8 mm for Euro Adapter - SP008578 Red wire liner ,0.9-1.0 mm for Euro Adapter - SP008856

View more View less
